Max Pro 12" Dvc Woofer

Lanzar's MAX PRO-series speakers are designed with the professional in mind - and they'll push your audio to the MAX! This 12' small-enclosure sub with dual voice coils will add extra punch to your low-end and give you that huge sound you want. The sound is produced by a 2' dual-layer high-temperature Kapton voice coils with two 80 oz. heavy double-stacked magnets, pushing 1600 watts MAX power. It's all housed in a stamped plastic basket with a hex key input terminal for heavy-duty stability. And your booming sound is enhanced by the wide, non-fatiguing rubber suspension, specially designed rubber magnet boot, and the bumped and vented motor construction. Dual 4 ohm impedance.

DETAILS

Black Non-Pressed Paper Cone

Specially Treated Foam Edge Suspension

Stamped Plastic Basket w/Hex Key Input Terminal

Bumped Vented Motor Structure

Custom Designed Rubber Magnet Boot

2'' Dual Layer High Temperature Kapton Voice Coil

80 + 80 oz. Heavy Double Stacked Magnet Structure

1600 Watts Peak Power

Dual 4 Ohms Nom. Impedance

Fs: 40Hz, Qms:5.0, Qes: 0.90, Qts: 0.75, SPL: 84(dB), Vas: 5.204(Cuft)

Mounting Depth: 5.76"

MANUALS & DOWNLOADS

MAXP124D - Manuals
